Additional information
| Weight | 21 kg |
|---|---|
| Dimensions | 75 × 73 × 193 cm |
| IP Video Input | 32-ch |
| Two-way Audio Input | 1-ch, RCA |
| Incoming Bandwidth | 160Mbps |
| Outgoing Bandwidth | 64Mbps |
| Remote Users | 128 |
| HDMI/VGA Output | HDMI1/VGA: 1920x1080p /60Hz, 1920x1080p /50Hz, 1600×1200 /60Hz, 1280×1024 /60Hz, 1280×720 /60Hz, 1024×768 /60Hz |
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Audio Compression | 1-ch, RCA |
| Synchronous Playback | 32-ch |
| Compression | H.265/H.264 |
| Liveview/Playback | 8MP/6MP/5MP/4MP/3MP/1080p/960p/720p/D1/2CIF/CIF |
| Capability | 4 x 4K@30, 8 x 4MP@20, 16 x 1080p@25, 32 x 720p@25 |
| SATA | 4 SATA interfaces |
| Capacity | up to 10TB for each disk |
| Network Interface | 1 RJ-45 10M/100M/1000M self-adaptive Ethernet Interface |
| Network Function | HTTP,HTTPS,UPNP, RTSP,RTP, SMTP, NTP, DHCP, DNS,IP Filter, PPPOE, DDNS, FTP, IP Server, P2P |
| Serial Interface | 1 x RS-485 |
| USB Interface | Rear Panel: 1 x USB2.0, Front Panel: 1 x USB2.0 |
| Alarm In | 4-ch |
| Alarm Out | 1-ch |
| Power Output | 12 VDC |
| POE Interface | 16 Independent 100 Mbps PoE network interfaces |
| Supported Standard | interfaces IEEE 802.3at |
| Power Supply | 100 ~ 240 VAC |
| Consumption | ≤ 20 W |
| PoE | Max 30W for single port Max 200W in total ( 12.5W for each ) |
| Working Environment | -10°C ~ + 55°C ( +14°F ~ +131°F ) |
| Working Humidity | 10% ~ 90% |
| Weight (without HDD) | 5KG (11.02lb) |
